FEATURES

• Measures Active/Reactive Energy, Maximum Demand, and Power Factor
• Enables bidirectional and time-of-use metering during simultaneous power import and export; supports Type 1, 2, and 3 tariff rates
• Stores load profile (LP) data for up to 65 days
• Built-in battery preserves metering data and keeps the clock running during power outages
• Features self-diagnostics for memory, battery, voltage loss, and wiring errors, along with direct load control, overcurrent limiting, and anti-tamper functions
• Equipped with RS485 communication, enabling AMR and OMR remote metering, and supporting the DLMS communication protocol.
• Instrumentation : instantaneous THD for the energy quality, average voltage, average current of each phase and save instantaneous voltage THD for past 3 days
• Meets IP54 dust and water resistance standards for outdoor use
